ZH-50 Rotary
Type Automatic Cartoner Machine
ZH-50 旋轉式自動裝盒機
Application:
This
machine is widely used in pharmaceutical, food, food supplement, cosmetic and
small hardware industry. The main function of the machine is to open pre-made box
automatically, then operator manually or automatically fill materials into box
and the machine seal the box automatically.
應用范圍：
該設備廣泛的運用于制藥，食品，保健品，化妝品及小五金行業。主要功能是將預制好的盒子打開，然后人工裝料或者自動裝料，設備再自動將紙盒封上。
Main
Feature:
1. Special
designed for the clients who gets different sizes box but with small production
capacity.
2. Easy change part.
3. Vertical design with rotary turret:
simple operation with easier cleaning.
4. All
Stainless Steel 304 overall parts.
5. Touch
screen with PLC Control
6. Available
to connect the machine with Bottling machine, labeling machine, blistering
machine or another other automatic production machinery.
7. Available for Hot Melt glue sealing.
8. Batch
Number Embossing or Printing (Optional)
9. Automatic
Feeding Leaflet (Optional)
特點：
1. 專門為多尺寸小批量生產的客戶設計。
2. 設備小而巧，更換規格簡單便捷。
3. 設備采用立式設計并帶旋轉式轉盤，操作簡單易于清潔。
4. 整機外包不銹鋼304，干凈整潔，符合GMP要求。
5. 本機采用PLC控制人機界面操作系統，生產參數一目了然。
6. 本設備可以跟瓶裝線，貼標機，鋁塑包裝機及其他自動設備聯機為自動生產線設備。
7. 本機亦可于熱熔膠機配套。
8 本機可于生產批號打印設備聯機。
9. 本機亦可以裝配自動說明書塞入功能。
主要性能技術參數：
SPECIFICATION :
|
項目/型號
Model No.
|
ZH-50
|
|
包裝速度
Production speed:
|
20-50盒/分鐘box per min
|
|
紙盒的最大尺寸
Max.Size
|
200 x 80 x
80mm
|
|
紙盒的最小尺寸
Min. Size
|
60 x 20 x 20
mm
|
|
紙盒紙質要求
Box
Quality
|
250-350g/m3
|
|
電機功率
Motor Power
|
1/4HP 15:1
|
|
電源類型
Power supply
|
單相220V 50/60HZ single phase
|
|
機器噪音
Machine noise
|
≤80dB
|
|
氣 源
Air Pressure
|
0.5-0.8 Mpa
|
|
耗 氣 量
Compress air consumption
|
150L/min
|
|
外形尺寸
Machine measurement:
|
L 1100 x W 1500 x H 1900 mm
|
|
整機重量
Machine weight
|
450Kg
|
